Regulations
D.M. 21/03/73 aqueous, fatty foods and alcohol up to 95% vol.
3-A Sanitary Std. N°18-03 CLASS II.Arrêté Français 05/08/2020 cat. D.
BfR ed. 21 - XXI Cat. 2 for fatty foods.
Bisphenol A free. FDA tit.21 art. 177.2600 aqueous and fatty foods.Japan Ministry of Health and Welfare Notification No. 370, 1959–Specific. and Standards for Food, Food Additives, Etc. T<100°C.
Phthalates free (REACH Reg.).
Heavy metal tested. Reg. EC 1935/2004. Reg. EC 2023/2006.
/ Food /
Dijon Easy
High quality multipurpose food hose, compatible with the EasyShell System
Highlights
High level of purity
Flexible and easy to handle
EasyShell System
Application
hardwall corrugated hose for suction and delivery of many food products as olive oil, wine, beer, fruit juices, fatty foods, milk and alcohol up to 95°. Suitable for loading-unloading operations in tank truck transport processes and in food industry plants.
Temperature
from -30°C (-22°F) to +100°C (+212°F).
Construction
Tube:
Reinforcement:
Cover:
white, smooth, food quality, taste free and odourless synthetic rubber. 100% phthalates free.
Reinforcement:
high strength synthetic cord and embedded helix wire.
Cover:
blue, corrugated (wrapped finish) food quality synthetic rubber, ozone and weathering resistant.
Branding:
white/red/gold continuous stripe "IVG Food (family logo) Dijon Easy...".
Available upon request
- Hardwall hose with smooth cover.
| Code | Inside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 1498878 | 25 | 1 | 10 | 150 | 30 | 450 | 0,79 | 0,53 | 75 | 3,0 | 0,9 | 60 | 200 |
| 1500031 | 32 | 1 1/4 | 10 | 150 | 30 | 450 | 1,00 | 0,67 | 95 | 3,7 | 0,9 | 60 | 200 |
| 2300121 | 38 | 1 1/2 | 10 | 150 | 30 | 450 | 1,14 | 0,77 | 115 | 4,5 | 0,9 | 60 | 200 |
| 1498282 | 51 | 2 | 10 | 150 | 30 | 450 | 1,59 | 1,07 | 150 | 5,9 | 0,9 | 60 | 200 |
| 1501020 | 60 | 2 23/64 | 10 | 150 | 30 | 450 | 1,84 | 1,24 | 185 | 7,3 | 0,9 | 60 | 200 |
| 2300123 | 63,5 | 2 1/2 | 10 | 150 | 30 | 450 | 1,9 | 1,28 | 195 | 7,7 | 0,9 | 60 | 200 |
| 1502794 | 76 | 3 | 10 | 150 | 30 | 450 | 2,38 | 1,60 | 225 | 8,9 | 0,9 | 60 | 200 |
