Regulations
Tube: phthalates free.
Cover: according to ISO 22196:2011 (Ref.1).
Tube rubber is made with materials according to FDA tit. 21 art. 177.2600 and BfR XXI Cat. 3.
/ Hot /
Easyclean
Extruded hot water washing hose
Highlights
Extruded hose
Antimicrobial cover, fat resistant
Compliant with food regulations
Application
hot water washing hose in food environment with excellent resistance to high temperatures. Suitable for hygenic operations in dairies, canneries, slaughterhouses and all food processing industries. Particularly fat resistant cover. Not suitable for conveying food.
Temperature
from -20°C (-4°F) to +95°C (203°F).
Construction
Tube: white, seamless synthetic rubber, fat resistant.
Reinforcement: high, strength synthetic fabrics.
Cover: antimicrobial, blue, seamless synthetic rubber, aeging, ozone and fat resistant.
Reinforcement: high, strength synthetic fabrics.
Cover: antimicrobial, blue, seamless synthetic rubber, aeging, ozone and fat resistant.
Branding: IVG EASYCLEAN - WASHDOWN IN FOOD INDUSTRIES - W.P. 10 BAR - SIZE - 95°C - BATCH NUMBER.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | m | ft | |
| 1466267 | 13 | 1/2 | 21,4 | 0,84 | 10 | 150 | 30 | 450 | 0,34 | 0,23 | 80 | 3,2 | 60 | 200 |
| 1466275 | 16 | 5/8 | 25 | 0,99 | 10 | 150 | 30 | 450 | 0,43 | 0,29 | 95 | 3,7 | 60 | 200 |
| 1466283 | 19 | 3/4 | 28,4 | 1,12 | 10 | 150 | 30 | 450 | 0,52 | 0,35 | 115 | 4,5 | 50 | 164 |
| 1466291 | 25 | 1 | 35 | 1,38 | 10 | 150 | 30 | 450 | 0,7 | 0,47 | 155 | 6,1 | 40 | 131 |
