Ivg Colbachini | Flexible Rubber Hose

Regulations

  • EN 12115
EN 12115:2021 (16 bar).
Oil
/ Oil /

Spezia LL

Fuel and oils suction and delivery hose

Highlights

Aromatic content up to 50%
Suitable for ATEX environment
According to EN 12115

Application

hardwall hose used for the suction and delivery of mineral oils, unleaded gasoline and fuels with aromatic content up to 50%.
Hose suitable for use in an ATEX environment. Tested by the notified body INERIS.

Temperature

from -30°C (-22°F) +80°C (+176°F).

Electrical Resistance

Ω/T, electrically conductive hose. Electrical resistance guaranteed for lengths equal or lower than 60 m.

Construction

Tube: black, smooth, NBR1 conductive rubber.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: black, smooth (wrapped finish), synthetic rubber, weathering, abrasion, ozone and oil resistant.
Branding: continuous embossed marking according to EN 12115 + continuous yellow brand “IVG Oil (family logo)...”.

Available upon request

  1. Softwall hose.

Request information

I declare that I have read the privacy policy pursuant to EU Regulation 2016/679

Spezia_LL_it.pdf
Spezia_LL_en.pdf
Spezia_LL_de.pdf
Spezia_LL_fr.pdf
Spezia_LL_ru.pdf
Spezia_LL_cn.pdf
IVG_sd_atex_it.pdfatex_it.pdf
IVG_sd_atex-en.pdfatex-en.pdf
IVG_sd_atex_ted.pdfatex_ted.pdf
IVG_sd_atex_fr.pdfatex_fr.pdf
IVG_sd_atex_cn.pdfatex_cn.pdf
See all documents
Code Inside diameter Outside diameter Working pressure Burst pressure Weight nominal Bending radius Vacuum Length max
mm inch mm inch bar psi bar psi kg/m lbs/ft mm inch bar m ft
2200450 19 3/4 31 1,22 16 240 64 960 0,69 0,46 120 4,7 0,9 120 400
2200451 25 1 37 1,46 16 240 64 960 0,85 0,57 150 5,9 0,9 120 400
2200452 32 1 1/4 45 1,77 16 240 64 960 1,1 0,74 175 6,9 0,9 120 400
2200453 38 1 1/2 51 2,01 16 240 64 960 1,39 0,93 225 8,9 0,9 120 400
1501860 50 2 66 2,60 16 240 64 960 2,08 1,40 275 10,8 0,9 120 400
2200455 63,5 2 1/2 79,5 3,13 16 240 64 960 2,72 1,83 315 12,4 0,9 120 400
1501879 75 2 61/64 91 3,58 16 240 64 960 3,24 2,18 375 14,8 0,9 120 400
1499750 100 4 118 4,65 16 240 64 960 4,88 3,28 500 19,7 0,9 120 400
