Silprime

Regulations

  • FDA
  • Reg. CE 1935/2004
  • Reg. CE 2023/2006
Tube and cover BfR XV.  Tube and cover ISO 10993 (5-10-12).

Phthalates free (Reg. REACH, Annex XVII).

  Tube and cover USP class VI.  FDA tit.21 art.177.2600 aqueous foods.  Reg. EC 1935/2004.  Reg. EC 2023/2006.
Pharma
/ Pharma /

Silprime

Pharmaceutical, cosmetic and biotech industry

Highlights

High purity hose

Reliable in service

Available with fittings

Application

softwall hose suitable for the food, cosmetic, pharmaceutical and biotech industry, where it is necessary to use flexible hoses made with high performance elastomers and excellent purity, biocompatibility and mechanical characteristics.

Temperature

-60°C (-76°F) +200°C (+392°F) depending on medium.

Branding:

continuous blue brand “IVG Pharma (Family Logo)...”.


Request information

I declare that I have read the privacy policy pursuant to EU Regulation 2016/679

Request information

I declare that I have read the privacy policy pursuant to EU Regulation 2016/679

Code Inside diameter Outside diameter Working pressure Burst pressure Weight nominal
mm inch mm inch bar psi bar psi kg/m lbs/ft
202400338 16 5/8 27 1,06 14 210 42 630 0,42 0,28
1501704 19 3/4 30 1,18 13 195 39 585 0,48 0,32
1500260 25 1 36 1,42 10 150 30 450 0,59 0,40
202400339 32 1 1/4 43 1,69 8 120 24 360 0,73 0,49
1502921 51 2 63 2,48 6 90 18 270 1,27 0,85
