Regulations
Tube USP class VI.
Tube ISO 10993 (5, 10, 11).
Tube: Reg. EU 10/2011 aqueous and fatty foods.
Tube FDA tit. 21 it. 177.1550, cover FDA tit.21 it. 177.2600.
Cover BfR XV and XXI cat.2.
Cover 3-A Sanitary Standard Class I.
In the production of Pharma hoses, IVG does not intentionally add substances such as phthalates, derivatives of animal origin subject to restrictions according to EC Reg. 1907/2006 (REACH).
/ Pharma /
Pharmatef SIL
Pharmaceutical, cosmetic and biotech industry.
Highlights
White silicone on cover
High performance
Available with fittings
Application
suction and delivery hose of chemical and food products. Particularly suitable in the chemical, cosmetic, pharmaceutical and biotech industry, where it is necessary to use flexible hoses made with high performance elastomers and excellent mechanical and chemical characteristics. Silicone rubber on cover.
Temperature
from -40°C (-40°F) to 150°C (+302°F).
Branding:
white/blue/red transfer tape “IVG Pharma...” and embossed marking “work order”.
Available upon request
1. Electrical grade M structure.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 2100645 | 13 | 1/2 | 23 | 0,91 | 10 | 150 | 40 | 600 | 0,46 | 0,31 | 50 | 2,0 | 0,9 | 12 | 40 |
| 2100646 | 19 | 3/4 | 29 | 1,14 | 10 | 150 | 40 | 600 | 0,61 | 0,41 | 70 | 2,8 | 0,9 | 12 | 40 |
| 1495275 | 25 | 1 | 35 | 1,38 | 10 | 150 | 40 | 600 | 0,76 | 0,51 | 90 | 3,5 | 0,9 | 12 | 40 |
| 2100647 | 32 | 1-1/4 | 43,5 | 1,71 | 8 | 120 | 32 | 480 | 1,04 | 0,62 | 120 | 4,7 | 0,9 | 12 | 40 |
| 2100648 | 38 | 1-1/2 | 50 | 1,97 | 7 | 105 | 28 | 420 | 1,31 | 0,79 | 140 | 5,5 | 0,9 | 12 | 40 |
| 2100643 | 51 | 2 | 63 | 2,48 | 7 | 105 | 28 | 420 | 1,7 | 1,01 | 180 | 7,1 | 0,9 | 12 | 40 |
