Regulations
EN 16820 design B.
Reg. EC 1935/2004. Reg. EC 2023/2006.Tube USP class VI.
Tube ISO 10993 (5, 10, 11).
Tube: Reg. EU 10/2011 aqueous and fatty foods.
Tube FDA tit. 21 it. 177.1550.
In the production of Pharma hoses, IVG does not intentionally add substances such as phthalates, derivatives of animal origin subject to restrictions according to EC Reg. 1907/2006 (REACH).
/ Pharma /
Pharmatef omega
Pharmaceutical, chemical, cosmetic and biotech industry
Highlights
EN 16820 design B
High performance
Available with fittings
Application
suction and delivery hose of chemical and food products. Particularly suitable in the chemical, cosmetic, pharmaceutical and biotech industry, where it is necessary to use flexible hoses made with high performance elastomers and excellent mechanical and chemical characteristics.
Temperature
from -40°C (-40°F) to 150°C (+302°F).
Electrical Resistance
Ω - C according to ISO 8031 spec.
Branding:
white/blue/red transfer tape "IVG Pharma..." and embossed marking "EN 16820: 2017 - IVG - Design B - FEP - SD - ID - 16bar - -40°C/+150°C - Ω-C - Q/Year - work order".
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 2300026 | 13 | 1/2 | 25 | 0,98 | 16 | 240 | 64 | 960 | 0,5 | 0,34 | 80 | 3,1 | 0,9 | 40 | 130 |
| 2300027 | 19 | 3/4 | 31 | 1,22 | 16 | 240 | 64 | 960 | 0,65 | 0,44 | 115 | 4,5 | 0,9 | 40 | 130 |
| 1499971 | 25 | 1 | 37 | 1,46 | 16 | 240 | 64 | 960 | 0,8 | 0,54 | 150 | 5,9 | 0,9 | 40 | 130 |
| 1498207 | 32 | 1-1/4 | 44 | 1,73 | 16 | 240 | 64 | 960 | 0,98 | 0,66 | 190 | 7,5 | 0,9 | 40 | 130 |
| 2300030 | 38 | 1-1/2 | 51 | 2,01 | 16 | 240 | 64 | 960 | 1,34 | 0,90 | 230 | 9,1 | 0,9 | 40 | 130 |
| 1499980 | 51 | 2 | 66,5 | 2,62 | 16 | 240 | 64 | 960 | 2,1 | 1,41 | 300 | 11,8 | 0,9 | 40 | 130 |
