Regulations
Tube: FDA tit 21 it. 177.1520 for foods.
Reg. UE 10/2011.
Tube: BfR III ed. 2021.
Tube: phthalates free (Reach Reg. Annex XVII).
EN 12115:2021. Reg. EC 1935/2004. Reg. EC 2023/2006.
/ Chem /
Clearcond LL
Conductive hose with white cover for chemicals and foods
Highlights
Non-staining white cover
It can be used in ATEX areas
Suitable for a wide range of chemicals and foods
Application
Suitable for conveying clean chemicals, paints, glues, alcoholic products, cosmetics, acidic and fatty food, hygienic-sanitary products, in fixed installations, tanks or barrels. The special inner tube finish, with a low coefficient of friction, facilitates the movement of the product conveyed. Hose suitable for use in an ATEX environment. Tested by the notified body INERIS.
Temperature
-30°C(-22°F) +100°C(212°F) depending on medium.
Electrical Resistance
Ω/T, electrically conductive hose. Electrical resistance for lengths equal to or lower than 20 m.
Branding:
continuous blue “IVG Chem...”. Embossed according to EN 12115.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 2400724 | 13 | 1/2 | 25 | 0,98 | 16 | 240 | 64 | 960 | 0,53 | 0,36 | 60 | 2,4 | 0,9 | 60 | 200 |
| 2400725 | 16 | 5/8 | 28 | 1,10 | 16 | 240 | 64 | 960 | 0,61 | 0,41 | 75 | 3,0 | 0,9 | 60 | 200 |
| 2400726 | 19 | 3/4 | 31 | 1,22 | 16 | 240 | 64 | 960 | 0,68 | 0,46 | 90 | 3,5 | 0,9 | 60 | 200 |
| 1501259 | 25 | 1 | 37 | 1,46 | 16 | 240 | 64 | 960 | 0,84 | 0,56 | 120 | 4,7 | 0,9 | 60 | 200 |
| 2400727 | 32 | 1 1/4 | 44 | 1,73 | 16 | 240 | 64 | 960 | 1,02 | 0,69 | 150 | 5,9 | 0,9 | 60 | 200 |
| 2400728 | 38 | 1 1/2 | 51 | 2,01 | 16 | 240 | 64 | 960 | 1,32 | 0,89 | 180 | 7,1 | 0,9 | 60 | 200 |
| 2400729 | 40 | 1 37/64 | 53 | 2,09 | 16 | 240 | 64 | 960 | 1,36 | 0,91 | 180 | 7,1 | 0,9 | 60 | 200 |
| 2500358 | 50 | 2 | 64 | 2,52 | 16 | 240 | 64 | 960 | 1,74 | 1,17 | 250 | 9,8 | 0,9 | 60 | 200 |
| 2400730 | 51 | 2 | 65 | 2,56 | 16 | 240 | 64 | 960 | 1,77 | 1,19 | 250 | 9,8 | 0,9 | 60 | 200 |
| 2400731 | 63,5 | 2 1/2 | 78 | 3,07 | 16 | 240 | 64 | 960 | 2,41 | 1,62 | 320 | 12,6 | 0,9 | 60 | 200 |
| 2500359 | 75 | 2 61/64 | 90 | 3,54 | 16 | 240 | 64 | 960 | 2,86 | 1,92 | 400 | 15,7 | 0,9 | 60 | 200 |
| 2400732 | 76 | 3 | 91 | 3,58 | 16 | 240 | 64 | 960 | 2,89 | 1,94 | 400 | 15,7 | 0,9 | 60 | 200 |
| 2400733 | 100 | 4 | 116 | 4,57 | 16 | 240 | 64 | 960 | 4,26 | 2,86 | 550 | 21,7 | 0,9 | 60 | 200 |
