Vapofer EN 6134
Steam hose for 210°C
Highlights
Application
Temperature
Construction
Tube:
Reinforcement:
Cover:
Reinforcement:
Cover:
Branding:
Available upon request
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | m | ft | |
| 1363603 | 13 | 1/2 | 27 | 1,06 | 18 | 270 | 180 | 2700 | 0,6 | 0,40 | 60 | 200 |
| 1335090 | 19 | 3/4 | 33,5 | 1,32 | 18 | 270 | 180 | 2700 | 0,87 | 0,58 | 60 | 200 |
| 1363581 | 25 | 1 | 40 | 1,58 | 18 | 270 | 180 | 2700 | 1,12 | 0,75 | 60 | 200 |
| 1363573 | 32 | 1/4 | 48 | 1,89 | 18 | 270 | 180 | 2700 | 1,4 | 0,94 | 60 | 200 |
| 1363646 | 38 | 1-1/2 | 54 | 2,13 | 18 | 270 | 180 | 2700 | 1,61 | 1,08 | 60 | 200 |
| 1363638 | 51 | 2 | 69 | 2,72 | 18 | 270 | 180 | 2700 | 2,55 | 1,73 | 60 | 200 |
